Power supplies


PCB Layout Design offers a complete line of power supplies and linear single and three phase 30 to 1 KW AC, DC or AC + DC




Fixed, adjustable, programmable arbitrary, low cost linear, switch mode or low noise.

Powerful, reliable and cost our power supplies are integrated into a self-ventilated enclosure by natural convection, therefore no operating noise. The mounting is on DIN rail or screw.

All power supplies incorporate an internal fuse protection against short circuits and overloads in high school.

The PCB Layout Design power supplies have a high efficiency and a holding time at full load for 70 ms which gives them an excellent resistance to cuts microphones.

Finally, all models are equipped with VDC output voltage is present and those above 60 W include a VDC power LED display and a correction of the power factor (PFC to IEC 1000-3-2).

PCB Layout Design also has in its catalog Battery testers, electronic loads, transformers and power converters to complement the range of the energy division.

Through our research, we can also offer you the feeds according to your specifications.



  • S 25 W to 750 W Single Output
  • TP 100 to 150 W triple output,
  • QP from 100 W to 200 W in quadruple output,
  • QP 100 and 150 with series B and C before and finally PSP 1000 and 1500 W


Others on request

  • DC / DC Converters: SD Series 25 W to W SD1000


Screw mounting DIN rail.
